Nine axis cantilever steel structure welding workstation

Commodity name：Nine axis cantilever steel structure welding workstation
Manufacturer： Xinbao Intelligent

Intelligent welding workstation, equipped with a nine axis cantilever and teaching free programming welding robot, the welding workstation has extremely high flexibility and accuracy. Welding H-beams, cow legs, tower legs, reinforcing plates, support plates, etc.

Message

Product Details

　　Multiple axes can provide more degrees of freedom, enabling robots to perform precise welding operations in various complex environments. This design is typically used to handle large, heavy, or differently shaped workpieces, as the nine axis configuration allows robots to approach and weld these workpieces at multiple angles and poses. Non teaching programming robots do not require traditional manual teaching methods for programming. It is based on visual weld seam recognition and tracking, allowing robots to autonomously recognize the geometric shape and weld seam position of workpieces, and then automatically calculate and generate corresponding welding paths. This greatly improves the automation and efficiency of welding.

　　With the continuous development of artificial intelligence and machine vision technology, there may be more teaching free programming and adaptive welding technologies applied to intelligent welding workstations in the future.
